Jaylor 6000HD Series mixers are designed for operators who need to move heavier loads over rougher terrain. Larger than standard 5000 series mixers, the HD series has a heavier frame, cast – dual walking beam axles and heavy duty wheels and tyres.
The 6000HD Series is available in a range of configurations with capacities from 27.2m3 to 36.7m3. Other enhancements, such as thicker auger flighting and floor, mean that it is possible to blend and transport mixes up to 75% heavier. HD Series mixers are class leaders in efficient and rapid processing of round or square feed into uniform rations in as little as three to five minutes.
Using 20% less horsepower and requiring less time per mix than conventional mixers — a Jaylor mixer reduces fuel consumption and ensures a longer operating life.
- Heavier frame, cast - dual walking beam axles and heavy duty wheels and tyres
- Thicker auger flighting and floor
- Capacities from 27.2m3 to 36.7m3
- Uniform rations in as little as three to five minutes
- Jaylor 6000 Series mixers come standard with Jaylor’s 19mm patented square cut auger
- Carbide-Coated Knives
Features
Sloped Top
Exclusive, patented design, prevents bale bridging, enabling rapid cutting and efficient mixing of even the toughest forages, enhancing overall feed quality.
Vertical Knives
Enhances cutting efficiency, reducing forage processing times and improving the distribution of high forage rations to ensure a cleaner, more uniform mix.
Slide Plate Technology
Gathers feed gently into the auger, reducing friction and cutting horsepower needs by 20%, which means lower energy costs and a smoother operation.
Square-Cut Edges
Patented design to reduce pressure on the mix, rapidly and efficiently process baled forage into a uniform TMR, that resists sorting and delivers consistent shaker box results.
Specifications
Heavy Duty Twin Auger - 6850HD
Capacity - 27.2 cubic metres
Min HP (PTO) - 135
PTO Speed - 1000
Knives - 18
Standard Extension - 16"
Heavy Duty Twin Auger - 61000HD
Capacity - 31.0 cubic metres
Min HP (PTO) - 155
PTO Speed - 1000
Knives - 22
Standard Extension - 16"
Heavy Duty Twin Auger - 61250HD
Capacity - 36.7 cubic metres
Min HP (PTO) - 200
PTO Speed - 1000
Knives - 26
Standard Extension - 16"
