Versatile and gutsy, the new generation Kioti compact CK4220 42hp Daedong diesel engine tractor comes with either manual or hydrostatic transmission. HST models feature performance proven, heavy duty HST drives that deliver power and efficiency. The three range transmission – high, mid, low – along with a twin pedal operation makes your job easier, smoother and safer. HST models employ a two pedal system for forward and reverse with smooth engagement, acceleration and deceleration. Pedal pressure is minimised, reducing operator fatigue during long hours of use and when doing repetitive tasks.
Manual transmission models feature 12 forward and 12 reverse speeds delivering heavy duty performance. Second and reverse gears are synchronised for efficient forward and reverse operations requiring frequent shifting. A maximum ground clearance of 340mm makes working on rocky or uneven terrain simpler.
- HST transmission or 12x12 transmission
- Twin pedal (HST version)
- High ground clearance
- Power steering
- Hydraulic remotes (STD)
Powerful Eco Friendly Engine
The powerful, environmentally-friendly 42hp Daedong engine offers quiet and smooth running with plenty of grunt.
HST models feature performance proven, heavy duty HST drives that deliver power and efficiency. Manual transmission models feature 12 forward and 12 reverse speeds delivering heavy duty performance.
Power Steering With Tilt
The standard power steering minimises the effort required to make tight, repetitive turns. The steering wheel tilts to adjust for operator needs.
Four Wheel Drive is standard on the CS4220 Tractor and a single lever engages the 4WD mode.
The illuminated dashboard ensures great visibility while working in bright daylight or at night.
3-Point Linkage & Rear Remotes
CAT-I 3-point hitch with a maximum lifting capacity of 740kg. The 540rpm PTO and dual remote hydraulic valves are standard
Deluxe Suspension Seat
The ergonomically designed, adjustable suspension seat allows the operator to ride in comfort no matter what the task may be.
The ergonomically designed work station places operator controls within easy reach and arranged in a logical manner.
Dual HST Pedals
HST models feature a two pedal system for forward and reverse with smooth engagement, acceleration and deceleration.
Liquid Cooled 3 Cylinder Diesel
42hp @ 2600RPM
34 Litre Fuel Tank Capacity
12x12 Synchro Shuttle or 3 Range Hydrostatic Drive
Cruise Control HST Models
Link Pedal System (HST Only)
4 Wheel Drive
Rear Differential Lock
Hydraulics & Linkage
44.4 l/min Total Flow
Category 1 Three Point Linkage
4 Hydraulic Remotes (2 Rear, 2 Front w/Joystick)
740kg Max Rear Lift Capacity 600mm Behind Lift
Industrial Front 25/8.5x14 Rear 15/19.5
Turf Front 27x18.5-15 Rear 41x14.00-12.4
Wet Disc Brakes
Deluxe A/C Cabin
Front Work Lights with Indicators/Brake Lights
Step Through Platform
Under Bonnet Muffler
Speed Range 1.52-23.56 km/h (Manual)
Infinite Speeds from 0-25 km/h F/R (HST)
Overall Length 3070mm
Overall Width 1400mm
Overall Height 2330mm
Ground Clearance 340mm
Total Weight - 1,500kg
Scott and Cathy Oates needed a functional, versatile tractor to help maintain their 10-acre lifestyle farm 30 minutes south of Hobart. The couple grow fodder for their horses on a property that is steeply sloped at the front and back. Scott went to Agfest to see what was available, discussed the options, and later took delivery of a Kioti 3710 HST from a local Kioti dealer.
“We chose the CK3710 HST because it’s a good solid tractor, well put together and simple to use. With the 4-in-1 loader, slasher and fencing auger, it was good value for money. I’ve used it for slashing, harrowing, spreading lime and fertilizer, taking out old fencing with the 4-in-1 bucket, and putting in new copper posts”
Greg Hems lives with his partner Diana on 15 acres at Ladys Pass, near Heathcote, Victoria, and needed a strong and versatile tractor to work the rolling, rocky terrain. Before buying, Greg did his research, comparing two other quality brands and visiting showrooms. He decided on a Kioti CK3010 compact tractor and is delighted with the results.
“The CK3010 is a very good tractor and the power to the hydraulics and 4-in-1 bucket has allowed us to do some big clearing jobs. It has a strong build and we haven’t been able to break it yet! It feels very safe and stable on the uneven ground here. I thought it would be louder but it’s quiet to operate, and it gives good hours for the fuel it uses”
