Kioti’s most Powerful Tractor!

The new Kioti PX1153 tractor has evolved from the PX1052, and is now geared up for more serious work than ever before. Still with the ever dependable 4.4 litre Perkins engine, the PX1153 received a full raft of upgrades to make it Kioti’s most powerful tractor.

A 115 hp engine, bigger hydraulic pumps, bigger radial tyres, deluxe air seat and electronic rear linkage with greater lifting capacity are just some of the great features.

  • 115 hp
  • Rugged and Dependable
  • New Style Bonnet
  • 74.8 L/min oil flow at remotes
  • Linkage control on fenders
  • Deluxe air seat
  • Electronic linkage control
  • 3,630 kg lift capacity

Features

Turbocharged, Intercooled Engine

The turbocharged Perkins engine with air-to-air intercooler ensures the PX1153 has all the power the operator requires. A dual air cleaner offers increased filtration which duly extends the filter life.

Large Fuel Tank

A large 120 litre fuel tank increases production work time without the need for frequent refuelling.

Main Gear Shift Lever

By using the hand clutch on the PX Series, the main gear lever can be shifted without using the clutch pedal. The operator can select the "hi" or "low" speed of any gear by simply pressing a button on the lever.

Power Shuttle

The Powershuttle lever enables easy back-and-forth operation, reducing operator fatigue. It provides softer shuttle operation and allows the operator to perform loader work without pressing the clutch pedal.

Ergonomic Design

The ergonomic layout and colour coding of the levers makes for easy operation.

Electronic Linkage Control

The ELC on the armrest provides accurate and straightforward control of the rear linkage.

Adjustable Steering Wheel and Instrument Panel

A tilting instrument panel and steering wheel allow the perfect fit for each operator.

3 Point Hitch External Control

The standard external fender control for lifting and lowering of the rear linkage increases the operator's convenience when attaching implements.

Headlights

Newly designed headlights making night time work easier and safer.

Deluxe Seat

The ergonomically designed cab comes with a fully adjustable air suspension seat allowing the operator to work in comfort.

Rear Lift Cylinders

Heavy rear linkage and two large assist cylinders with a lift capacity of 3630kg at 24" behind ball ends.

Wide Radial Tyres

Front: 440/65R24 Rear: 540/65R34

Specifications

ENGINE

Perkins 1104D-44TAG

Liquid cooled 4 cylinder

4399cc displacement

115 hp @ 2400rpm

120 Litre Fuel Tank Capacity

Dual Air Cleaner

TRANSMISSION

Synchro Mesh

Power Shuttle

Push Button Hand Clutch

Wet Multi Disc Clutch

32F x 32R Speed with Hydraulic High/Low

Rear Differential Lock

HYDRAULICS & LINKAGE

Main Pump Capacity - 74.8 l/pm

Steering Pump Capacity - 46.5 l/pm

Total Maximum Flow - 121.3 l/pm

3630kg Maximum Rear Linkage Lift Capacity

Power Steering

Category II Three Point Linkage

Position, Draft, Mixed Control Lift System

4 Rear Remote Outlets

Clevis Type Rear Draw Bar

PTO

Independent 540/1000 PTO

Auto PTO

BRAKES

Wet Disc Type

OPERATOR ENVIRONMENT

Deluxe Cabin with A/C and Heating

Radio

Adjustable Steering Wheel and Instruments

High Quality Fully Adjustable Seat With Arm Rests and Backrest

Flat Operator Platform

Front and Rear Wipers

Internal/External Air Exchanger Filters

12V Refrigerator

TRAVEL SPEEDS

Forward 0.65-39.64 kph Reverse 0.65-39.37 kph

DIMENSIONS

Overall Length incl. 3PL 4120mm

Overall Width Minimum Tread 2293mm

Overall Height 2750mm

Wheelbase 2305mm

Ground Clearance 475mm

Weight with Tyres 3702 kg

TYRES

Radial Front 440/65R24 Rear 540/65R34

PX1153 PC CAB Brochure

Click to view the PX1153 PC CAB brochure.

View Brochure
