RX6030 CAB | RX7030 ROPS & CAB | RX8030 ROPS & CAB
The Kioti RX Series tractors are fitted with a new streamlined hood which improves visibility for the operator. Maintenance is made easy with the hood opening to a 90 degree angle. Other improvements are larger tyres, 50% more lift capacity, higher road speed, increased fuel capacity and better hydraulic flow.
The RX Series is a versatile work-horse that will suit a variety of applications, such as vineyard work and loader work, and is compact enough to do smaller jobs around the farm. Some of the standard features are 24×24 transmission, 4WD power steering, forward reverse shuttle and independent rear PTO.
- 60 - 80HP Daedong Diesel Engines
- 24 x 24 Transmission
- 4WD Power Steering
- Forward Reverse Shuttle
- Independent Rear PTO
Kioti RX Series Walkaround
Familiarise yourself with the Kioti RX Series with this quick walkaround video.
Features
Engine
The powerful, environmentally friendly, turbo charged, 60 - 80 hp Daedong diesel engines offers high output, low noise, low vibration and lower fuel consumption.
Fuel Tank
The 85 (ROPS) and 95 (CAB) litre fuel tanks allow productive working hours without the need for frequent refuelling.
Maintenance
The vertical opening hood allows easy access to the air filter, fluid level service and inspection of electrical components.
Cabin
A step through platform provides easy access. Air conditioning, heating and ventilation, gives extra comfort for the operator in tough Australian conditions. All RX models with cabins are equipped with a radio / CD player, cup holders and sun visor.
Deluxe Suspension Seat
The ergonomically designed and fully adjustable suspension seat allows the operator to work in comfort. The seat backing incorporates a built-in pocket for storing of operator manuals.
Operator Station*
The intelligently arranged work station places operator controls within easy reach to enjoy a comfortable and smooth ride. *Cab model shown
Dashboard
Illuminated dashboard including tachometer, low fuel and high temperature warning.
Power Steering*
With hydraulic power steering, this tractor has a smooth responsive steering that requires minimal operator effort regardless of the task at hand. *RX7030 / RX8030 shown
PTO
SAE 1-3/8 Independent 6 spline PTO with auto-stop function (540 / 540E rpm)
Hydraulics
Standard dual remote hydraulic valves accommodate a wide variety of attachments and implements. A mid-mount double acting valve and a single lever joystick for loader operations are standard on the RX series. The RX series tractor has two external hydraulic lift cylinders with a lift capacity of 2,075 kg (RX8030 - 2,256 kg)
Heavy Duty Front Axle
Twin Hydraulic Pump
Implement Pump 41.6 l/min Power Steering Pump 26 l/min (RX8030 31.2 l/min)
Specifications
Engine
Kioti 4B243DTM-A (RX6030) | 4F243DTP-A (RX7030 CAB) | 4FT-TP2-A (RX8030 CAB) | 4F243DTP-A (RX7030 & RX8030 ROPS)
Liquid Cooled 4 Cylinder Diesel Turbo
2600cc Displacement (RX6030) | 2435cc Displacement (RX7030 & RX8030)
60HP @2600rpm (RX6030) | 70HP @2600 rpm (RX7030) | 80HP @2600rpm (RX8030)
85L Fuel Capacity (RX7030 Cab, RX7030 & RX8030 ROPS ) | 95L Fuel Capacity (RX6030 & RX8030 CAB) |
Transmission
24 Forward Speeds/24 Reverse Speeds (RX6030) | Power Shuttle (RX7030 & RX8030)
Synchro Fwd/Rev Shuttle (RX6030) | Main Gear x6 Range Gear Shift (RX7030 & RX8030)
Creep Range (RX6030) | 24Fx24R Speed (RX7030 & RX8030)
4 Wheel Drive (RX6030) | 4 Wheel Drive with Wet Multi Disc Engagement (RX7030 & RX8030)
Hydraulics & Linkage
67.6 L/PM Total Flow (RX6030 & RX7030)
72.8 L/PM Total Flow (RX8030)
Category II three point linkage
Drawbar
4 hydraulic remotes (2 x rear, 2 x front)
2,256kg rear lift capacity
PTO
Independent
Electro-Hydraulic Engagement (RX6030)
Auto PTO (RX6030)
540 / 750 rpm Rear PTO Speed (RX6030)
SAE 1-3/8, 6 Spline (RX7030 & RX8030)
Brakes
Wet Multi Disc Type
Operator Environment
High Quality Fully Adjustable Seat with Backrest
Adjustable Steering Wheel and Instruments
Flat Operator Deck
Deluxe Cabin with A/C & Heating (RX6030, RX7030 & RX8030 Cab)
Front Wiper (RX6030, RX7030 & RX8030 Cab)
Internal / External Air Exchanger Filters(RX6030, RX7030 & RX8030 Cab)
Travel Speed
Forward 0.16 - 36.36km/h (RX6030-RX7030)
Reverse 0.16 - 35.75km/h (RX6030-RX7030)
Forward 0.17 - 37.86km/h (RX8030)
Reverse 0.17 - 37.23km/h (RX8030)
Dimensions - RX6030 CAB
Overall Length: 3685mm
Overall Height: 2630mm
Overall Width: 1800mm
Wheelbase: 2100mm
Ground Clearance (Min): 420mm
Weight: 2630kg
AG Tyres Front: 11.2 - 20
AG Tyres Rear: 14.9 - 30
Dimensions - RX7030 & RX8030 CAB
Overall Length: 3685mm
Overall Height: 2655mm
Overall Width (min Tread) 1800mm (RX7030) | 1960mm (RX8030)
Wheelbase: 2100mm (RX7030) | 2130mm (RX8030)
Ground Clearance (Min): 420mm (RX7030) | 230mm (RX8030)
Weight: 2630kg (RX7030) | 2795kg (RX8030)
AG Tyres Front: 11.2 - 20 (RX7030) | Radial Tyres Front: 280 / 85R24 (RX8030)
AG Tyres Rear: 14.9 - 30 (RX7030) | Radial Tyres Rear: 420 / 85R30
Dimensions - RX7030 & RX8030 ROPS
Overall Length: 3685mm
Overall Height: 2730mm
Overall Width (min Tread): 1800mm
Wheelbase: 2100mm
Ground Clearance (Min): 420mm
Weight 2360kg (RX7030) | 2540kg (RX8030)
AG Tyres Front 11.2 - 20 (RX7030) | Radial Tyres Front 280 / 85R24 (RX8030)
AG Tyres Rear 14.9 - 30 (RX7030) | Radial Tyres Rear 420 / 85R30 (RX8030)
RX Series Brochure
Click to view the latest brochures.
View BrochureKioti RX6030 Cab Series Brochure
Kioti RX7030 & RX8030 CAB Series Brochure
Kioti RX7030 & RX8030 ROPS Series Brochure
Customer Reviews
Craig – Kioti RX8030 ROPS
Craig, who operates a variety of agricultural tasks on his property in Lower Chittering, W.A, relies on his Kioti RX8030 ROPS for a range of jobs. What makes Craig’s Kioti stand out is its combination of comfort and precision. He’s particularly impressed by the driving comfort, tight turning circle, shuttle shift, and electric PTO. With frequent tasks like flail mowing and raking for silage, Craig finds that the easy access to get on and off the tractor and the fantastic maneuverability around trees make a huge difference in his day-to-day work.
View Full Review
Andrew – Drysdale, Victoria (RX Series)
Andrew Belfrage is an agricultural contractor, doing hay, ploughing, spraying, sowing and other work in the Geelong and Bellarine regions of Victoria. Prior to buying his first Kioti, the RX7030 cabin tractor with 4-in-1 loader, Andrew researched other makes and models before deciding on Kioti. Given his subsequent experience, he would recommend Kioti to anyone.
“The RX7030 is a well-built, versatile tractor with plenty of power for a diverse range of operations and pretty good fuel economy. Kioti tractors are more user friendly; the cabin is very comfortable [and] it has all the specs and features I’ve been looking for, and is very easy to operate”
